Цифров осцилоскоп

50,00 $
Няма данък
Количество
Наличен

Модел: DSO150

2,4 инчов TFT дисплей

Захранващ адаптер в комплекта

Измервателна сонда в комплекта

Specifications:

Maximum Real-time Sampling Rate: 1MSa/s

Analog Bandwidth: 0-200KHz

Sensitivity Range: 5mV/div-20mV/idv

Maximum Input Voltage: 50Vpk (1X probe)

Input Impedance: 1M ohms/20pF

Accuracy: 12 Bits

Record Length: 1024 points

Coupling Modes: DC / AC / GND

Time Base Range: 500s/Div - 10us / Div

Trigger Modes: Auto, Normal, and Single

Trigger Position: Center of Buffer

Supply Voltage: DC 9V(8-10V)

Current Consumption:~120mA @ 9V

Main Board Size: 94 * 65mm / 3.7 * 2.56in

Analog Board Size: 65 * 47mm / 2.56 * 1.85in

Screen Size: 52 * 40mm / 2 * 1.57in

Package Size: 14.5 * 10 * 3.7cm / 5.7 * 3.94 * 1.45in

Package Weight: 179g / 6.33oz
