Bee venom collector controller (ver. Pro, project)

$50.00
Tax excluded

Model: 00149PT

Type of the components: THT

Number of layers: 2

Dimension of the PCB: 97 x 69 mm

Quantity
In-stock

  World delivery

Reliable Service

  Online support

E-mail us



Visit our Facebook page

Attention! This is not a real device - only project for direct manufacturing (PCB and assembling)

After purchasing this product, you will receive a download link on your email.

Model: 00149PT

Type of the components: THT

Number of layers: 2

Dimension of the PCB: 97 x 69 mm

The downloadable ZIP file contain the files:

Gerber

Drill

BOM

Pick and Place

High resolution schematic

List of components

Short manual

PCB files for printing (top and bottom)

_________________________________

Device for collecting bee poison. Not kill the bees. Not dangerous for the humans. The board no need any soldering

NOTE: This device is a kit-board, Without collecting frames and their glasses.

Characteristics:

Power: 11 - 15V battery or power adapter

Connecting frames: up to 10

Adjusting output voltage: yes

Adjusting output frequency: yes

Timer for OFF devive after fixed time: yes

Reverse voltage protection

Low battery indication

Consumption: 80 mA

Dimension of the PCB: 97 x 69mm
