PI metal detector (Project)

60,00 $
Няма данък

Pulse induction metal detector

Project for direct manufacturing (PCB and assembling)

Model on the New Hobby: NH-204-v2

Type of the components: THT

Number of layers: 2

Dimension of the PCB: 112 x 86 mm

The downloadable ZIP file contain files:




Pick and Place

High resolution schematic

List of components

Short manual

PCB files for printing (top and bottom)

No any brands on the board.


Low reaction for stones, consists iron and ferrous oxides

Possibility to use small, normal and big coils

You can use this metal detector for:

  - General purpose metal detector

  - Searching on the beach

  - Underwater metal detector

  - Searching meteorites

  - Searching gold (nugget)

  - Detector for deep searching


Model on New Hobby: NH-204

Principle: Pulse Induction

Mode: non-motion

Search coil: White (not included, choose diameter from the site)

Indication: LCD display, sound

Ground compensation

Power: 12V,  reverse polarity protection

Low battery alarm

Consumption: 80-100 mА

Dimensions of PCB: 85 x 110 mm
