Цифров осцилоскоп

39,00 $ Спестявате 9,00 $
48,00 $
Няма данък
Количество
Наличен

Performance

Maximum real-time sampling rate : 1Msps

Accuracy : 12Bit

Sampling buffer depth : 1024 bytes

Analog bandwidth : 0 - 200KHz

Vertical Sensitivity : 10mV / Div - 5V / Div ( 1-2-5 progressive manner )

Adjustable vertical displacement , and with instructions

Input impedance : 1MΩ

Maximum input voltage : 50Vpp (1: 1 probe ), 400Vpp (10: 1 probe )

Coupling modes include DC / AC / GND

The horizontal time base range : 10μs / Div - 50s / Div ( 1-2-5 progressive manner )

With automatic, regular and one-shot mode , easy to capture the moment waveform

Available rising or falling edge trigger

Adjustable trigger level position , and with instructions

Observable trigger waveform before ( negative delay )

Can freeze at any time waveform display (HOLD function )

Comes 1Hz /3.3V square wave test signal source
