PI metal detector (00126LS Project)

100,00 $
Без данък

Pulse induction metal detector

Model on 1-PCB.com: NH-126LS

Type of the components: SMD

Number of layers: 2

Dimension of the PCB: 123 x 34 mm

Количество
В наличност

  Бърза доставка

Доставка до офис на куриер или адрес.

  Работно време

От 9:00 до 17 часа



Посетете нашата Facebook страница

Attention! This is not a real device - only project for direct manufacturing (PCB and assembling)

Pulse induction metal detector

Model on 1-PCB.com: NH-126LS

Type of the components: SMD

Number of layers: 2

Dimension of the PCB: 123 x 34 mm

The downloadable ZIP file contain files:

Gerber

Drill

BOM

Pick and Place

High resolution schematic

List of components

Short manual

PCB files for printing (top and bottom)

____________________________________

Low reaction for stones, consist iron and ferrous oxides

Possibility to use small, normal and large coils.

Very suitable to creating underwater metal detector

You can use it for:

   - Underwater metal detector

  - Searching meteorites

  - Searching gold (nugget)

  - General purpose metal detector

  - Searching on the beach

  - Detector for deep searching

Characteristics:

Model on New Hobby: 00126LS

Principle: Pulse induction

Mode: non-motion

Search coil: description in manual

Sensitivity: 25 cm for small coin, 30 cm for big coin.

Indication: sound, 10 LEDs

Power: 12V

Consumption: 65-75 mА

Dimensions of PCB: 123 x 34 mm

00126LS-DP
